• 2-position thermal reset limit thermostat with single-pole changeover microswitch
• Switching capacity
contact connection 1-2: 16 (2.5) A, AC 250 V
contact connection 1-3: 6 (2.5) A, AC 250 V
• Time constant conforming to DIN EN 14597
• 3 mounting choices: pipe, pocket or wall mounting
• Adjusted switch-off temperature can be checked through the viewing window in the housing
• IP43 and IP65 protection class available
• Push-in terminals for fast installation
• Switching capacity
contact connection 1-2: 16 (2.5) A, AC 250 V
contact connection 1-3: 6 (2.5) A, AC 250 V
• Time constant conforming to DIN EN 14597
• 3 mounting choices: pipe, pocket or wall mounting
• Adjusted switch-off temperature can be checked through the viewing window in the housing
• IP43 and IP65 protection class available
• Push-in terminals for fast installation
RAK-TW.1000HB , RAK-TW.1200HP, RAK-TW.1200B-H, RAK-TW.1000S-H, RAK-TW.1200S-H
